Current location: home pageProducts - Cable protection
  • Product name: Ultra thin wall Zero halogen,flexible heat shrink tubing
  • Data name: Ultra thin wall Zero halogen,flexible heat shrink tubing_Cable protection
Ultra thin wall
Flexible
Zero halogen
 Flame retardant
Continuous Operating Temperature:-45℃ to 125℃
Shrink Temperature:120℃
RoHS and Sony Compliant
Download

Product details

Size(mm)

Internal diameter(mm)

After Recovery(mm)

Standard Package m/spool

Download

Internal diameterMax(mm)

Wall thicknessNom(mm)
Φ1.0CB1.40±0.20≤0.650.20±0.10200下载
Φ1.5CB1.90±0.20≤0.850.20±0.10200下载
Φ2.0CB 2.40±0.20 ≤1.00 0.22±0.10 200 下载
Φ2.5CB2.90±0.20≤1.300.25±0.10200下载
Φ3.0CB3.40±0.20≤1.500.28±0.10200下载
Φ3.5CB3.90±0.20≤1.800.28±0.10200下载
Φ4.0CB4.40±0.20≤2.00.30±0.10200下载
Φ4.5CB 4.90±0.20 ≤2.30 0.30±0.10 100 下载
Φ5.0CB5.50±0.20≤2.500.32±0.10100下载
Φ6.0CB6.50±0.20≤3.000.32±0.10100下载
Φ7.0CB7.50±0.20≤3.500.32±0.10100下载
Φ8.0CB8.50±0.30≤4.000.32±0.10100下载
Φ9.0CB9.50±0.30≤4.500.35±0.10100下载
Φ10CB10.50±0.30≤5.000.35±0.10100下载
Φ11CB11.50±0.30≤5.500.40±0.10100下载
Φ12CB12.50±0.30≤6.000.40±0.10100下载
Φ13CB13.50±0.30≤6.500.40±0.10100下载
Φ14CB14.50±0.40≤7.000.40±0.10100下载
Φ15CB15.50±0.40≤7.500.40±0.10100下载
Φ16CB16.50±0.40≤8.000.40±0.10100下载
Φ17CB17.50±0.40≤8.500.40±0.10100下载
Φ18CB18.50±0.20≤9.000.42±0.10100下载
Φ20CB20.50±0.20≤10.00.45±0.10100下载
Φ22CB22.50±0.20≤11.00.45±0.10100下载
Φ25CB25.50±0.20≤12.50.45±0.1050下载
Φ28CB28.50±0.20≤14.00.45±0.1050下载
