Product details
notes1）符合 WEEE(ROHS) | notes2）Part Number | TF.Tf Rated Functioning Temperature | Operating Temperature | TH Th (℃) | TM Tm(℃) | Rated Current | Rated Voltage | UL | VDE | BEAB | PSE | Download |
| 〇 | SF 70K | 73 | 70±2 | 45 | 150℃ | notes2） 6A | AC250V |
E71747 | 677802 | C1180 | 1008 | Drawing |
| 〇 | SF 76K | 77 | 76±04 | 51 | Drawing | |||||||
| 〇 | SF 91K | 94 | 91±31 | 66 | 1010 | Drawing | ||||||
| 〇 | SF 96K | 99 | 96±2 | 71 | Drawing | |||||||
| 〇 | SF119K | 121 | 119±2 | 94 | 1012 | Drawing | ||||||
| 〇 | SF188K | 192 | 188±31 | 164 | 1015 | Drawing | ||||||
| 〇 | SF214K | 216 | 241±13 | 198 | notes3） | 1016 | Drawing |
1）No use of hazardous substances prescribed by WEEE and ROHS.
2)The following electrical ratings were used for the UL,VDE and KTL safety sandards:10A(Resistive)/AC 250V.
3)The following SF-types have passed the Conductive Heat Aging Test(CH)specified by the UL safety standard:SF188K and SF214K.
