Current location: home pageProducts - AUTOMOBILE TIES AND CONNECTOR CLIPS
  • Product name: AUTOMOBILE TIES RQX
  • Data name: AUTOMOBILE TIES RQX_AUTOMOBILE TIES AND CONNECTOR CLIPS
One-piece fir-tree design with disc is similar to push mount cable ties but the disc can enhance the stability of fixing and avoid dust and water invasion
Additional cured tab below the buckle will fasten and maintain bundles on the axial.Fir-tree push mount design applied to varied to varied thickness of board or one-side thread hole
Applied to different industries such as automotive,aviation,white goods manufacture,and panel building
Specifications supplied by customers’ order
Material:Nylong 66,UL94 V2
Color: Black
Download

Product details

Part No.

Length A

mm

Width B

mm

Hole Dla

mm

Panel Thickness

mm

Max.Bundle Dia

mm

Download

RQX-9955 165 5.2 7.0~9.5 1.3 38 Drawing
RQX-9956 165 5.2 7.0~9.5 1.3 38 Drawing
RQX-9961 175 5.2 7.4*13.0/6.5*13.0 0.8~2.8 38 Drawing
